PAM4 BiDi 100m 100G Optical Transceivers QSFP28-100G-BIDI LC Connector

Ask Lasest Price
Brand Name :	Gvdlink
Model Number :	GVD-QSFP-100G-BIDI
Certification :	CE,ROHS,FCC
Price :	Negotiable
Payment Terms :	T/T, Western Union, MoneyGram, L/C,Paypal
Supply Ability :	3500pcs per week
Delivery Time :	1-5 working days

Add to Cart

Product Details
Company Profile

PAM4 BiDi 100m 100G Optical Transceivers QSFP28-100G-BIDI LC Connector

02313EEK QSFP28-100G-BIDI Compatible QSFP 100G PAM4 BiDi 100m transceiver

Description

item	Description
Part number	02313EEK QSFP28-100G-BIDI
Version support	Supported in V200R001C00 and later versions
Transceiver form factor	QSFP28
Transmission speed	100GE
Center wavelength (nm)	850/910
Standards compliance	100G PAM4 BiDi
Connector type	LC
Type of the end face of the fiber ceramic ferrule	PC or UPC
Applicable cable and maximum transmission distance	Multimode fiber (OM3) (with diameter of 50 μm): 70 m Multimode fiber (OM4) (with diameter of 50 μm): 100 m
Modal bandwidth	Multimode fiber (OM3): 2000 MHzkm Multimode fiber (OM4): 4700 MHzkm
Transmit power (dBm)	-2.4 to +3
Maximum receiver sensitivity (dBm)	-5.9
Overload power (dBm)	3.5
Extinction ratio (dB)	≥ 3
Operating temperature	10°C to 70°C

Our advantages

Advantages	Applications
100% tested	OTN OTU4 Metro Area Networks
fully product line	100GBASE Ethernet Data Center Networks
High Quality with ISO9001 , TUV , CE , FCC , UL and RoHS certificates
3 year Warranty

Huawei QSFP28 100G Product series

Part number	Model	Description
02311KNU	QSFP28-100G-LR4	100GBASE LR4 QSFP LC 10km
02311MNM	QSFP28-100G-PSM4	100GBASE-PSM4 QSFP 500m
02311GBW	QSFP28-100G-SR4	100GBASE-SR4 850nm 100m
02313EEK	QSFP28-100G-BIDI	100G PAM4 BiDi 850/910nm 100m
02311MNP	QSFP-100G-CLR4	100GBASE-CLR4 1271/1291/1311/ 1331nm 2km
02311MNN	QSFP-100G-CWDM4	100GBASE-CWDM4 1271/1291/1311/ 1331nm 2km
02312UJN	QSFP-100G-CWDM4-500	100GBASE-CWDM4 1271/1291/1311/ 1331nm 500m
02311UPS	QSFP-100G-LR4-Lite	100GBASE-LR4 1295/1300/1304/1309nm 2km
02312DAT	QSFP-100G-eCWDM4	100GBASE-eCWDM4 1271/1291/1311/1331 10km
02311YXR	QSFP-100G-ER4-Lite	100GBASE-ER4 1295/1300/1304/1309nm 40km
02311QUK	QSFP-100G-SWDM4	100G-SWDM4 850nm 100m

Guarantee

Our products are compatible with Cisco , Ciena , H3C , Extreme , HP , Foundry , Avaya , D-link , Alcatel , Riverstone , Enterasys , Netgear , Nortel , Juniper , Ruijie , Zyxel , Huawei , etc .
