3m QSFP-40G-CU3M 40G QSFP+ DAC Cable for Huawei 02310MUH

Description

The Huawei QSFP-40G-CU3M direct attach copper cable assembly (also known as DAC) is suitable for very short distances and offers a highly cost-effective way to establish a 40 Gigabit link connectivity between devices using QSFP ports. The QSFP+ DAC cable is designed for 40Gb/s high-speed interconnecting networking applications such as high-performance computing (HPC), enterprise networking including top-of-rack switching and network storage markets.

Features (Low Power Version)

• Lower cost than QSFP+ optical transceiver and active optical cable (AOC)
• Maximum aggregate data rate: 40 Gb/s (4 x 10Gb/s)
• Hot-pluggable QSFP+ 38-PIN footprint
• Single 3.3V power supply
• Compliant with IEEE 802.3ba 40GBASE-CR4 standard
• Compliant with QSFP+ MSA SFF-8436
• Compliant with Infiniband QDR/DDR data rates
• Maximum 1.5W operation power
• Operating temperature range: 0 to 70°C
• RoHS Compliant and Lead-Free

Benefits
• Cost-effective copper solution
• Lowest total system power solution
• Lowest total system EMI solution
• Optimized design for Signal Integrity

​Our HW QSFP copper 40G cables product series

Applications

• 40 Gigabit Ethernet

• 10 Gigabit Ethernet

• InfiniBand 4x SDR , DDR , QDR

• 2 , 4 , 8 , 10 Gigabit

• SAS , Servers , Hubs , Switches , Routers

• Fiber Channel Fiber Channel over Ethernet
